QHY 268M 26 MP CMOS APS-C Monochrome Astronomy Camera
Starizona
From $2,199.00
3 stores
The QHY268M is a 26 Megapixel cooled, back-illuminated, monochrome CMOS camera based on the Sony IMX571 sensor with native 16-bit A/D and 3.76um pixels. The camera has only 0.7 electron of read noise at its highest gain and 6.8 FPS at full resolution readout speed, making it ideal for deep-sky astrophotography with exceptional sensitivity and low noise performance. The two-stage cooling system allows you to reduce the chip's temperature -35°C below ambient temperature for >1 second exposures and -30°C below ambient in higher frame rate scenarios. The round body and sensor size make this camera ideal for Hyperstar and RASA systems.
High Point Scientific
QHY268 Monochrome Photographic APS-C CMOS Camera
Ships to US only
$2,199.00
Starizona
268M 26 MP CMOS APS-C Monochrome Astronomy Camera
Worldwide shipping
$2,399.00
Agena Astro
QHY 268M Pro 26 MP APS-C CMOS Cooled Astronomy Camera - Professional Monochrome Version
Worldwide shipping
$3,739.00
Specifications
| Read Noise (High Gain) | 0.7 |
| Sensor Array | 6252 x 4176 |
| Quantum Efficiency (Peak) | 90% |
| Weight | 855 lb |
| Bit Depth | 16 |
| Cooling Capability | 35 °C |
| Cooling Type | Dual-stage thermoelectric |
| Maximum Frame Rate | 6.8 fps |
| Interface | USB 3.0 |
| Resolution | 26″ |
| Full Well Capacity | 51 |
| Sensor type | Back-illuminated CMOS APS-C |
| Amplifier Glow | Zero |
| Sensor Model | Sony IMX571 |
| Pixel Size | 3.76 μm |
| Dark Current at -20C | 0.0005 |
| Back Focal Length | 12.5 mm |
| Full Well Capacity (Extended Mode) | 75 |
| Image Buffer | 1 |
