Astroprices

ASI294MC

ZWO

From $699.00

6 stores

In stock

The ZWO ASI294MC is a versatile one-shot color camera equipped with Sony's IMX294CJK Micro-4/3 format sensor and 11.7 megapixel resolution with large 4.63-micron pixels ideal for high signal-to-noise ratio imaging of deep-sky objects. It's equally well-suited for fast, high-resolution lunar, solar, and planetary imaging. The back-illuminated sensor achieves exceptional quantum efficiency of over 75% with a 14-bit ADC delivering 13 stops of dynamic range, combined with an impressive 63,700-electron full-well capacity to prevent star saturation. The cooled Pro model integrates two-stage TEC cooling to reduce sensor temperature 35 degrees Celsius below ambient for low-noise deep-sky astrophotography.

Specifications

Sensor resolution 4144
Sensor pixel size 4.63
Sensor read noise 1.2
Sensor type CMOS Chip (Sony IMC294)
Sensor Sony IMX294CIK
Sensor diagonal 23.2
Megapixels 11.7 MP
Full Well Capacity 63700
Sensor Format 4/3 (Micro Four-Thirds)
USB Interface USB 3.0
ADC Bit Depth 14
Dynamic Range 13
Quantum Efficiency Peak 75%
Frame Rate at Full Resolution (14-bit) 16 fps
Frame Rate at Full Resolution (10-bit) 19 fps
Cooling Reduction (Pro Model) 35 °C
