ASI1600MM Pro
ZWO
From $1,280.00
2 stores
In stock
The ZWO ASI1600MM Pro is a 16-megapixel monochrome CMOS camera featuring a Panasonic 4/3" sensor with 4656x3520 resolution and 3.8μm pixels, designed as one of the best-selling cooled monochrome astronomy cameras. Its integrated two-stage TEC cooling reduces sensor temperature to 35-40°C below ambient to keep noise low, enabling imaging of faint deep-sky objects, and includes a 256MB DDR3 buffer for stable data transfer. The camera achieves fast USB 3.0 transfer at up to 14.7 fps at full 4656x3520 resolution with 12-bit ADC, making it ideal for wide-field deep-sky imaging, planetary work, and solar observation with filter wheels.
Specifications
| Sensor pixel size | 3.8 |
| Sensor type | CMOS |
| Sensor | Panasonic MN34230 |
| Sensor diagonal | 21.9 |
| Sensor read noise | 1.2 |
| Sensor resolution | 4656 |
| Resolution | 16″ |
| Pixel Size | 3.8 μm |
| Read Noise | 1.2 |
| Weight | 410 lb |
| Body Diameter | 78 mm |
| Back Focus Distance | 6.5 mm |
| Cooling Capability | 40 °C |
| Quantum Efficiency Peak | 60% |
| Maximum Frame Rate (12-bit full resolution) | 14.7 fps |
| Memory Buffer | 256 |
| Cooling System | Two-stage TEC |
| Maximum Frame Rate (10-bit full resolution) | 23 fps |
| Dynamic Range | 12.5 |
| Operating Temperature Range | -5 °C |
| Maximum Frame Rate (640x480) | 125 fps |
| Storage Temperature Range | -20 °C |
| Exposure Range | 32 microseconds to 2000 seconds |
| ADC | 12-bit |
| Full Well Capacity | 20 |
| USB Interface | USB 3.0 and USB 2.0 |
