Trius PRO-814C
Starlight Xpress
From ~$2,064.82
3 stores
In stock
The Starlight Xpress Trius PRO-814C is a high-resolution, one-shot color CCD camera featuring a 9.19-megapixel Sony ICX814AQ Exview sensor with 3.69-micron pixels, ideal for both planetary and deep-sky imaging through fast-focus telescopes and Hyperstar systems. Its redesigned electronics provide exceptional low read-noise performance, rapid 2.8 million pixels-per-second download speeds, and reliable two-stage Peltier cooling that reaches -45°C with an argon-filled chamber to eliminate dew and moisture. The integrated triple USB 2.0 hub allows direct connection of accessories like filter wheels and autoguiders while USB 2.0 connectivity enables full computer control.
Specifications
| Resolution | 9.19″ |
| Image Format | 3388 x 2712 |
| Pixel Size | 3.69 μm |
| Sensor type | ICX814AQ Exview CCD |
| Color Capability | Single-shot color (Bayer matrix) |
| Cooling Reduction | -45 °C |
| Read Noise | 3 |
| Download Speed | 2.8 s |
| Download Time (1x1 binning) | 3.5 s |
| Peak QE Yellow Light | 77% |
| QE H-alpha | 60% |
| Power Consumption | 1.5 W |
| Operating Voltage | 12 V |
| USB Ports | 3 |
| USB Hub Power Per Port | 200 mAh |
| Data Output Format | 16-bit |
| CCD Chamber | Argon filled |
