Atik 16200 Cooled Color CCD Camera
ATIK
From $4,127.00
3 stores
In stock
The ATIK 16200 is Atik's highest-resolution cooled CCD imaging camera, featuring a large APS-H format KAF-16200 color sensor with 16.2 megapixels ideal for wide-field and deep-sky astrophotography. With a 35mm sensor diagonal and 6-micron pixels, it delivers excellent compatibility with a wide range of telescopes while maintaining low noise performance through dual-stage Peltier cooling and an argon-purged chamber design. The camera's substantial imaging area and fine pixel scale make it equally suited for capturing expansive celestial vistas or revealing intricate details on the faintest objects in the night sky.
Specifications
| Sensor type | KAF-16200 Color CCD |
| Resolution | 16.2″ |
| Pixel Array | 4500 x 3600 |
| Pixel Size | 6 μm |
| Sensor Format | APS-H |
| Sensor diagonal | 35 |
| Sensor Dimensions | 27.2 |
| Quantum Efficiency | 60% |
| Read Noise | 9 |
| Cooling Type | Dual-Stage Peltier |
| Maximum Cooling Delta | 50 °C |
| Typical Cooling Temperature | -45 °C |
| Maximum Cooling Temperature | -50 °C |
| Interface | USB 2.0 High Speed |
| Power Supply | 12 V |
| Telescope Connector | M54 x 0.75 |
| Working Distance | 19.5 mm |
| Dimensions | 110 x 110 x 110 |
| Weight | 1.3 lb |
| Shutter Type | Mechanical Blade Shutter |
| Filter Size | 2 in |
| Color Filter Array | Bayer (Red/Green/Blue) |
